Description:
1. Switching power supply, convert AC 110V-220V to DC 12V 5A/DC 24V 2.5A.
2. Wide input voltage range, widely used in kinds of DC equipments, DC motor stepless speed adjustment, battery charging, Industrial
automation, LED light strip display, student experiment, communications, etc.
3. Protections: Over-load, Over- voltage, Over-current, Short-circuit.
Specification:
Product: Switching Power Supply
Type: AC/DC power
Model: YY-60
Transistor Connection: Full bridge
Input: AC 110-260V±15% 50HZ/60HZ
Output: 12V/24V±5%
Rated Power: 60W
Modulation Mode: PFM
Cooling Fan Type: Intelligent temperature control
Working Temperature: -10℃~+60℃
Working Humidity: 20% ~ 90%RH (no condensation)
Size: 110*78*36mm
Package Included:
1 X Switching Power Supply
